Akuvox A02 Administrator's Guide

Akuvox A02 Access Control Terminal Admin Guide
www.akuvox.com
15
Note
• You can only set the NTP-related parameter after you enable the automatic
date and time.
• Automatic Date&Time Enabled: if enabled, the device will update the time
automatically via the NTP server (Network Time Protocol). Disable it if you want to
set up the time manually.
• Time Zone: select the specific time zone based on where the device is used. The
default time zone is GMT+0:00.
• Preferred Server: enter the primary NTP server address you want to update the time
with. The default NPT server address is 0.pool.ntp.org
• Alternate Server: enter the backup NPT server address you want to update the time
with when the primary one failed.
• Update Interval: set the time update interval. For example, if you set it as 3600s, then
the device will send a request to the NPT server for the time update once every 3600
seconds.
• Current Time: display the current device time.
• Date/Time: set the date and time for the device manually when you disable the
automatic date and time service.

Akuvox A02 Specifications

General

Interface	Ethernet
Case design	-
Event capacity	100000
Number of users	20000 user(s)
Card holders quantity	20000
Maximum number of doors	1 door(s)
Supported network protocols	IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Ethernet LAN data rates	10, 100 Mbit/s
DC voltage range	12 V
Power consumption	600 mA
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	33 mm
Width	86 mm
