Akuvox A02 Administrator's Guide

Akuvox A02 Access Control Terminal Admin Guide
www.akuvox.com
43
Parameter Set-up:
• Power On: select Power on, if you want the device to perform Autop every time it
boots up.
• Repeatedly: select Repeatedly, if you want the device to perform Autop according to
the schedule you set up.
• Power On + Repeatedly: select Power On + Repeatedly if you want to combine
Power On mode and Repeatedly mode that will enable the device to perform Autop
every time it boots up or according to the schedule you setup.
• Hourly Repeat: select Hourly Repeat if you want the device to perform Autop every
hour.
18.4 DHCP Provisioning Configuration
Auto-provisioning URL can also be obtained using DHCP option which allows device to
send a request to a DHCP server for a specific DHCP option code. If you want to use
Custom Option as defined by users with option code ranging from 128-255), you are
required to configure DHCP Custom Option on the web interface. To set up DHCP AutoP
with Custom Option and Power on mode. And export Autop Template to edit the
configuration. Then set up DHCP Option on System > Auto Provisioning > DHCP Option
interface.

Akuvox A02 Specifications

General

Interface	Ethernet
Case design	-
Event capacity	100000
Number of users	20000 user(s)
Card holders quantity	20000
Maximum number of doors	1 door(s)
Supported network protocols	IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Ethernet LAN data rates	10, 100 Mbit/s
DC voltage range	12 V
Power consumption	600 mA
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	33 mm
Width	86 mm
