Akuvox A02 Administrator's Guide

Akuvox A02 Access Control Terminal Admin Guide
www.akuvox.com
45
Note
• The general configuration file for the in-batch provisioning is with the format
r0000000000xx.cfg, taking A01 as an example, r000000000101.cfg (10
zeros in total). While the MAC-based configuration file for the specific device
provisioning is with the format, MAC_Address of the device.cfg, for example,
0C110504AE5B.cfg.
does not need to specify this. To make it work, you need to configure the DHCP
server for option 43 with the updated server URL in it.
18.5 Static Provisioning Configuration
You can manually set up a specific server URL for downloading the firmware or
configuration file. If an Autop schedule is set up, the access control terminal will perform
the auto provisioning on a specific time according to the Autop schedule you set up. In
addition, TFTP, FTP, HTTP, and HTTPS are the protocols that can be used for upgrading
the device firmware and configuration. To download the Autop template first and set up
Autop server on System > Auto Provisioning > Manual Autop interface.
Parameter Set-up:
• URL: set up TFTP, HTTP, HTTPS, and FTP server addresses for the provisioning.

Akuvox A02 Specifications

General

Interface	Ethernet
Case design	-
Event capacity	100000
Number of users	20000 user(s)
Card holders quantity	20000
Maximum number of doors	1 door(s)
Supported network protocols	IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Ethernet LAN data rates	10, 100 Mbit/s
DC voltage range	12 V
Power consumption	600 mA
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	33 mm
Width	86 mm
