Akuvox A02 Administrator's Guide

Akuvox A02 Access Control Terminal Admin Guide
www.akuvox.com
44
Note
• The custom Option type must be a string. The value is the URL of the TFTP
server.
Parameter Set-up:
• Custom Option: enter the DHCP code that matched the corresponding URL so that
the device will find the configuration file server for the configuration or upgrading.
• DHCP Option 66: if none of the above is set, the device will automatically use DHCP
Option 66 for getting the upgrade server URL. This is done within the software and
the user does not need to specify this. To make it work, you need to configure the
DHCP server for option 66 with the updated server URL init.
• DHCP Option 43: if the device does not get an URL from DHCP Option 66, it will
automatically use DHCP Option 43. This is done within the software and the user

Akuvox A02 Specifications

General

Interface	Ethernet
Case design	-
Event capacity	100000
Number of users	20000 user(s)
Card holders quantity	20000
Maximum number of doors	1 door(s)
Supported network protocols	IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Ethernet LAN data rates	10, 100 Mbit/s
DC voltage range	12 V
Power consumption	600 mA
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	33 mm
Width	86 mm
