Akuvox A02 Administrator's Guide

Akuvox A02 Access Control Terminal Admin Guide
www.akuvox.com
22
• Local Relay + Web relay: if it is selected, both the local relay and web relay will
be triggered for the door opening. In the DTMF code door opening, if the web
relay and local relay share the same DTMF code, the local relay will be triggered
first.
• IP Address: enter the web relay IP address provided by the web relay manufacturer.
• User Name: enter the User name provided by the web relaymanufacturer.
• Password: enter the password provided by the web relay manufacturer. The
password is authenticated via HTTP and you can define the passwords using HTTP
Get in Action.
• Web Relay Action: enter the specific web relay action command provided by the web
manufacturer for different actions by the web relay. http://
admin:admin@192.168.1.2/state.xml?relayState=2.
After the web relay is set up, you can configure the specific web relay to be triggered based
on the relay location for the door access. To configure the configuration on web Directory
> User > Access Setting interface. You need to click +Add tab to turn to the Access Setting
interface.

Akuvox A02 Specifications

General

Interface	Ethernet
Case design	-
Event capacity	100000
Number of users	20000 user(s)
Card holders quantity	20000
Maximum number of doors	1 door(s)
Supported network protocols	IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Ethernet LAN data rates	10, 100 Mbit/s
DC voltage range	12 V
Power consumption	600 mA
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	33 mm
Width	86 mm
