Chassis Rear Panel
Fan tray slot numbers are printed along the top-rear of the chassis.
OS9907 Rear Panel Components
Fan Tray Slots 1 through 3 Support three fan trays, with three fans per tray for N+1
fan redundancy
Grounding Block Location shown in diagram above
Wrist Strap Grounding Connector Location shown in diagram above
