16
Power Supplies
Note: Mixing of AC and DC power supplies is not supported. Mixing of Hi
(240VAC) and Low (110VAC) input is not supported.
OS99-PS-A (AC Power Supply)
OS99-PS-D (DC Power Supply)
OS99-PS-A Specifications
Input Voltage/Current 100 VAC (13.8A) to 240V AC (16.5 A)
Max Output Power/Current 1200 W/21.4 A
3000 W/53.5 A
Dimensions 1.63 in x 4 in x 17.2 in
Weight 4.8 lb (2.18 kg)
Hot Swapping Supported
Provides Power for System and PoE
OS99-PS-D Specifications
Input Voltage/Current -40 VDC to -72 VDC / 75 ADC (At input voltages > 40 VDC)
Max Output Power 2500 W (44 - 58 VDC)
Max Output Current 44.6 A @ 56 VDC
Dimensions 1.63 in x 4 in x 17.2 in
