Managing Power over Ethernet (PoE)
Important: Alcatel-Lucent Enterprise recommends that PoE-enabled switches
with attached IP telephones have operational power supply redundancy at all
times for 911 emergency requirements.
In addition, both the switch and the power supply should be plugged into an
Uninterruptible Power Source (UPS).
Power over Ethernet Specifications
Module(s) supporting PoE OS99-GNI-P48
IEEE Standards supported IEEE 802.3; 802.af; 802.3at
PoE Power Supported Ports 1 through 8 support HPoE (75 W)
Ports 9 - 48 support 802.3at PoE (30 W)
All PoE-enabled ports are IEEE 802.3af/at compliant.
Default PoE administrative
status
Enabled
Default PoE operational status Disabled (PoE must be activated via the lanpower start
command.)
Power over Ethernet Settings Default Related Command
PoE operational status Disabled lanpower slot service
Total power available to a port 75000 milliwatts on ports 1
through 8; 30000 milliwatts
on ports 9 through 48
lanpower power
Total power available to an
entire slot
1800W lanpower slot maxpower
Power priority level for a port low lanpower priority
Capacitor detection method Disabled lanpower capacitor-detection
Priority disconnect status Enabled lanpower slot priority-disconnect
