Chassis Front Panel
OS9907 Front Panel Components
Slot 1 Supports Chassis Management Module (CMM) only
Slot 2 Supports a CMM (for 1+1 CMM redundancy) or NI module
(to maximize port count)
Slots 3 through 7 Support NI modules only
Slots PS1 through PS4 Support up to four load-sharing chassis power supplies,
offering N+1 redundancy
Wrist Strap Grounding Connector Location shown in diagram above
