11
Switch Fabric
OS9907-CFM
Each OS9907-CFM installed provides 1280Gbps of switch fabric bandwidth to chassis management and
the Network Interface (NI) modules. The chassis provides four (4) OS9907-CFM slots. The modules
connect to the chassis mid-plane and are located just behind the system fan trays.
CFM Specifications
Switch Fabric Bandwidth 1280Gbps
Number of Slots 4 (Slots CFM 3 and CFM 4 are currently inactive
and are reserved for future use.)
Power Consumption 119W
