10
Note. Because OS99-CMMs provide splitter cable support on QSFP+ ports, port
LED behavior for these switches differs from other OS9900 modules. To manually
configure network LED colors, refer to the interfaces beacon command in the
OmniSwitch AOS Release 8 CLI Reference Guide.
Solid Yellow Up Up Yes No No 1G (SFP+)
4X10G (QSFP+)
Solid BlueUpUpYesNoYesN/A
Blinking
Green
Up Up Yes Yes No 10G (SFP+)
40G (QSFP+)
Blinking
Yellow
Up Up Yes Yes No 1G (SFP+)
4X10G (QSFP+)
Blinking
Blue
Up Up Yes Yes Yes N/A
White N/A N/A Yes N/A N/A 4X10G
QSFP+
LED Display
Admin
Status
Link Status Transceiver Traffic VFL Port Speed
1G/10G (SFP+)
40G/4X10G
(QSFP+)
