LAG Hashing Fields used for 7210 SAS-Mxp
Table 12: LAG Hashing mechanism for services configured on 7210 SAS-Mxp devices
Services and Traffic Direction Packet fields used for Hashing for different traffic types
VPLS and Epipe Services:
SAP to SAP
SDP to SAP
All traffic (including VPLS Learnt and Unlearnt): Based on
LAG SAP parameters: service-id, lag_index,
encap_value, service_vlan, sap_index.
VPLS service:
SAP to SDP
IP traffic (Learnt and Unlearnt): Source and Destination IP,
Source and Destination L4 ports, Ingress Port-Id.
MPLS traffic: MPLS label stack (Two labels deep), Ingress
Port-Id.
Non-IP traffic (Learnt and Unlearnt): Source and Destination
MAC, EtherType, VLAN, Ingress Port-Id.
Epipe service:
SAP to SDP
IP traffic: Source and Destination IP, Source and Destination
L4 ports, Ingress Port-Id.
MPLS traffic: MPLS label stack (Two labels deep), Ingress
Port-Id.
Non-IP traffic: Source and Destination MAC, EtherType,
VLAN, Ingress Port-Id.
VPLS service:
SDP to SDP
All traffic: Source and Destination MAC (Outer MACs
inside the payload, just after the MPLS header), Ingress Port-
Id.
MPLS – LSR All traffic: MPLS label stack (Two labels deep), Ingress
Port-Id.
