LAG Hashing Fields used for 7210 SAS-X
Table 8: LAG Hashing mechanism for services configured on 7210 SAS-X devices
Services and Traffic Direction
(For example: SAP to SDP)
Packet fields used for Hashing for different
traffic types
VPLS service:
SAP to SAP
SAP to SDP
IP traffic (learnt and unlearnt) : Source and
Destination IP, Source and Destination L4 ports,
VLAN, Ingress Port-Id.
PBB traffic: BDA, BSA, ISID, Ingress Port-Id.
MPLS traffic: MPLS label stack (Two labels
deep), Ingress Port-Id.
Non-IP traffic (learnt and unlearnt): Source and
Destination MAC, EtherType, Ingress Port-Id.
Epipe service:
SAP to SAP
SAP to SDP
IP traffic : Source and Destination IP, Source and
Destination L4 ports, VLAN, Ingress Port-Id.
PBB traffic: BDA, BSA, ISID, Ingress Port-Id.
MPLS traffic: MPLS label stack (Two labels
deep), Ingress Port-Id.
Non-IP traffic: Source and Destination MAC,
EtherType, Ingress Port-Id.
VPLS and Epipe service:
SDP to SAP
All traffic: Source and Destination MAC (Outer
MACs inside the payload, just after the MPLS
header), Ingress Port-Id.
VPLS service:
SDP to SDP
All traffic: Source and Destination MAC (Outer
MACs inside the payload, just after the MPLS
header), Ingress Port-Id.
MPLS – LSR All traffic: MPLS label stack (Two labels deep),
Ingress Port-Id.
PBB VPLS service:
PBB BCB Traffic (that is, B-SAP
to B-SAP)
IP traffic (learnt and unlearnt): Source and
Destination IP, Source and Destination L4 ports,
Ingress Port-Id.
L2/non-IP traffic (learnt and unlearnt): BDA,
BSA, ISID, Ingress Port-Id.
