Interface Configuration
7210 SAS M, T, X, R6, R12, Mxp Interface Configuration Guide Page 11
Chassis Slots and Cards
The 7210 SAS-M are platforms which has a set of fixed ports and supports one expansion slot.
Software pre-provisions the cards on bootup. The expansion slot is represented as a MDA and
supported MDAs can be plugged into the expansion slot. The list of MDAs supported on 7210
SAS-M is available in the 7210 SAS release notes.
The following display output of show card command lists the cards auto-provisioned on 7210
SAS-M chassis:
Sample output for 7210 SAS-M:
A:7210# show card state
===============================================================================
Card State
===============================================================================
Slot/ Provisioned Equipped Admin Operational Num Num Comments
Id Type Type State State Ports MDA
-------------------------------------------------------------------------------
1 iom-sas iom-sas up up 2
1/1 m24-1gb+2-10gb m24-1gb+2-10gb up up 24
1/2 m4-ds1-ces m4-ds1-ces up up 4
A sfm-sas sfm-sas up up Active
The 7210 SAS-T, 7210 SAS-X, and 7210 SAS-Mxp are platforms which has a set of fixed port.
Software pre-provisions the cards on bootup. No expansion slots are supported on these platforms.
The following display output of show card command lists the cards auto-provisioned on 7210
SAS-X, 7210 SAS-T, and 7210 SAS-Mxp chassis:
Sample output for 7210 SAS-X:
A:7210-SAS-X>show# card
===============================================================================
Card Summary
===============================================================================
Slot Provisioned Equipped Admin Operational
Card-type Card-type State State
-------------------------------------------------------------------------------
1 iom-sas iom-sas up up
A sfm-sas sfm-sas up up/active
===============================================================================
A:7210-SAS-X>show#
Sample output for 7210 SAS-T:
