Alcatel-Lucent 7210 SAS M Interface Configuration Guide

LAG
Page 68 7210 SAS M, T, X, R6, R12, Mxp Interface Configu-
ration Guide
NOTES:
1. VPLS service, SDP to SDP: Test has been performed only for VC label variation with the
same Tunnel label.
2. In the LSR case, incoming labels are used for hashing.
3. ‘Learnt’ wherever mentioned corresponds to Destination MAC.
4. Source/Destination MAC refer to ‘Customer Source/Destination MACs’ unless otherwise
specified.
5. ‘service_id’ refers to the service id of the egressing VPLS/EPIPE/IES/VPRN service.
6. ‘lag_index’ refers to the Lag-IfIndex of the egressing lag.
7. 'encap_value' and 'service_vlan' are based on the inner/outer VLAN values of the
egressing LAG SAP.
8. 'sap_index' is a value assigned uniquely for each SAP internally.
ECMP Hashing fields used for 7210 SAS devices in Network mode
Table 13: ECMP Hashing mechanism for services configured on 7210 SAS devices in
IES (Multicast IP traffic)
IP interface (Network or SAP) to
IP interface (SAP)
IPv4 Multicast traffic: Software picks a port
Network Port IP interface
(Multicast IP traffic)
IP interface (Network or SAP) to
IP interface (Network)
IPv4 Multicast traffic: Source and Destination IP, Source and
Destination L4 ports, Ingress Port-Id.
Table 12: LAG Hashing mechanism for services configured on 7210 SAS-Mxp devices
Services and Traffic Direction Packet fields used for Hashing for different traffic types
