Appendix B Radio Information
B.1 WIFI Specifications
The Wifi Radio communications is in conformity with the standards 802.11a/b/g/n
This product is supplied with antennas EDA-8709-25GR2-A9 model number. Do not choose another antennas for ful-
filling the regulations.
Frequency Range 802.11b/g/n @ 2.4 GHz
2400-2483.5 MHz
802.11a/n (HT40) @ 5 GHz
5150-5250 MHz
2550-5350 MHz
5470-5725 MHz
Operating 802.11b/g/n (HT20) @ 2.4 GHz
13 Channels
802.11n (HT40) @ 2.4 GHz
9 Channels
802.11a @ 5 GHz
16 Channels
802.11n (HT40) @ 5 GHz
8 Channels
Average EIRP Power @ 2.4
GHz
(tolerance ± 1 dBm)
EIRP - Output Power @ 5 GHz
(tolerance ± 1 dBm)
2.4 GHz
802.11b @ 1 Mbps
2412 ~ 2472 MHz: +19 dBm
802.11g @ 6Mbps
2412 ~ 2472 MHz: +19 dBm
802.11n (HT20) MCS0
2412 ~ 2472 Mhz: +19 dBm
802.11n (HT40) MCS0
2422 ~ 2462Mhz: +19 dBm
5 GHz
802.11a @ 6 Mbps
5150 ~ 5725: +22 dBm
Radio Information Alcatel-Lucent Enterprise
44 OA58XX Router
