(Vendor: 0x10B5, Device: 0x8112)
(Subs. Vendor: 0x0000, Subs. Device: 0x0000)
Slot 1 - PCI device: bridge
(Bus: 12, Device: 14, Function: 0)
(Vendor: 0x1057, Device: 0x18C1)
(Subs. Vendor: 0x5444, Subs. Device: 0x1700)
Current production date: 11 23
Current software license: 28 60
S/N: 754/00111
BIOS MAC Add: 00-a0-26-a2-00-2c
>>
.....
....
TRYING APP DUMP
(CONFIGURED) appcode1.bin ver.: 0.11.0.1 0.0.0.0
APP0 CODE DUMP. Mode: 0....................................
APP0 DATA DUMP.............................................
APP CODE DUMP..............................................
APP DATA DUMP..............................................
Running application at: 0x00200140
Flash configuration read
Parsing text mode configuration ...
Configuration parsed
Initializing
Press any key to get started
3.3 Installation in a rack
The OA58XX can be installed in a 19” rack. To do this, you need two plastic strips like the ones shown below. The
strips and screws are not included in the basic packet and need to be acquired separately.
Both strips are attached to the device by means of 8 screws (4 on each side), as shown.
Fig. 26: Attaching the strips
The spaces for the screws in the OA58XX router leave the factory protected by covers. These can be removed with
a sharp tool (such as a small flat screwdriver). We recommend removing the upper cover to simplify the process.
Alcatel-Lucent Enterprise
3 Components and Power Supply
OA58XX Router 17
