alfa robot P650 - Handling and Transportation; Installation Dimensions

- 5-
Unit：mm
2.2 Installation Dimensions
For the Machine Platen:
Remark: Dimensions shown in ( ) are for the telescopic version
CAUTION: Pay close attention to the gravity center during handling with a
fork-lift and sure to avoid from dropping.
Lifting Point
CAUTION
Prevent Swing Safety Screw
Please make sure screw to be locked up
when transportation and take out the
screw before operation.
