1. Rear-I/O cover
2. Base cover
3. Rubber grip
4. USB Type-C board
5. Memory modules
6. I/O board
7. Fan and heat-sink assembly
8. System board
9. Speakers
10.Touchpad slot
11. Touchpad
12. Top heat-sink
13. Antenna holder
14. Display assembly
15.Audio board
16.Battery
17. M.2 2280 solid-state drive
18.M.2 2230 solid-state drive
19.Wireless card
20.Keyboard-controller board
21. Small fan
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These parts
are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for purchase
options.
Base cover
Removing the base cover
Prerequisites
1. Follow the procedure in
Before working inside your computer.
About this task
The following image(s) indicate the location of the base cover and provides a visual representation of the removal procedure.
