NOTE: Repeat the steps to install any other memory module into your computer.
NOTE: The securing clips return to a locked position. If you do not hear the click, remove the memory module and reinstall it.
Next steps
1. Install the
base cover.
2. Follow the procedure in After working inside your computer.
Wireless card
Removing the wireless card
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image(s) indicate the location of the wireless card and provides a visual representation of the removal procedure.
Steps
1. Remove the two screws (M2x3) that secures the wireless-card thermal shield to the wireless card and palm-rest and keyboard
assembly.
2. Slide and lift the wireless-card thermal shield.
3. Disconnect the antenna cables from the wireless card.
4. Slide and lift the wireless-card from the wireless-card slot.
25
