Steps
1. Place the heat-sink assembly on the system board.
2. Align the screw holes on the fan and heat-sink assembly to the screw holes on the system board.
3. In sequential order (1>2>3>4>5>6>7>8), tighten the eight screws (M2) that secure the fan and heat-sink assembly to the
system board.
4. Turn over the system-board assembly.
Next steps
1. Install the
rear-I/O cover.
2. Install the
top heat-sink.
3. Install the small fan.
4. Install the wireless card.
5. Install the M.2 2280 solid-state drive or M.2 2230 solid-state drive in slot one and two, whichever applicable.
6. Install the
M.2 2230 solid-state drive in slot three and four.
7. Install the base cover.
8. Follow the procedure in After working inside your computer.
Audio board
Removing the audio board
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the
memory module.
4. Remove the M.2 2230 solid-state drive in slot three and four.
5. Remove the M.2 2280 solid state drive or M.2 2230 solid-state drive in slot one and two, whichever applicable.
6. Remove the wireless card.
7. Remove the
small fan.
8. Remove the top heat-sink.
9. Remove the rear-I/O cover.
10.Follow the procedure from step 1 to step 16 in Removing the system board.
NOTE: The system board can be removed and installed along with the audio board, USB Type-C board, and heat sink-
assembly. This simplifies the removal and installation procedure and avoids breaking the thermal bond between the system
board and heat sink.
About this task
The following image(s) indicate the location of the audio board and provides a visual representation of the removal procedure.
66
