Touchpad
Removing the touchpad
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the
speakers.
About this task
The following image(s) indicate the location of the touchpad and provides a visual representation of the removal procedure.
Steps
1. Peel the tape from the touchpad bracket screw.
2. Remove the four screws (M2x2) that secure the touchpad bracket to the palm-rest and keyboard assembly.
3. Lift the touchpad bracket off the palm-rest and keyboard assembly.
40
