Power button
Removing the power button
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the memory module.
4. Remove the
M.2 2230 solid-state drive in slot three and four.
5. Remove the
M.2 2280 solid state drive or M.2 2230 solid-state drive in slot one and two, whichever applicable.
6. Remove the wireless card.
7. Remove the top heat-sink.
8. Remove the rear-I/O cover.
9. Follow the procedure from step 1 to step 16 in
Removing the system board.
NOTE: The system board can be removed and installed along with the audio board, USB Type-C board, and heat sink-
assembly. This simplifies the removal and installation procedure and avoids breaking the thermal bond between the system
board and heat sink.
About this task
The following image(s) indicate the location of the power button and provides a visual representation of the removal procedure.
71
