ZYNQ FPGA Development Board AX7021 User Manual
l
Amazon Store: https://www.amazon.com/alinx
29 / 54
CON1 Pin
Signal Name
ZYNQ Pin
CON1 Pin
Signal Name
ZYNQ Pin
1
+5V
-
2
+5V
-
3
+5V
-
4
+5V
-
5
+5V
-
6
+5V
-
7
+5V
-
8
+5V
-
9
GND
-
10
GND
-
11
PS_MIO13
A6
12
ETH_TXD0
E9
13
PS_MIO12
C5
14
ETH_TXD1
A7
15
-
-
16
ETH_TXD2
E10
17
-
-
18
ETH_TXD3
A8
19
GND
-
20
GND
-
21
-
-
22
ETH_TXCK
D6
23
-
-
24
ETH_TXCTL
F11
25
-
-
26
ETH_RXD3
A13
27
-
-
28
ETH_RXD2
F12
29
GND
-
30
GND
-
31
PS_MIO7
D5
32
ETH_RXD1
B7
33
PS_MIO8
E5
34
ETH_RXD0
E11
35
PS_MIO9
C4
36
ETH_RXCTL
D7
37
PS_MIO11
B4
38
ETH_RXCK
A14
39
GND
-
40
GND
-
41
-
-
42
ETH_MDC
D10
43
-
-
44
ETH_MDIO
C12
45
-
-
46
OTG_STP
A11
47
-
-
48
OTG_DIR
E8
49
GND
-
50
GND
-
51
XADC_VP
L11
52
OTG_CLK
A9
53
XADC_VN
M12
54
OTG_NXT
F9
55
-
-
56
OTG_DATA0
C7
57
PS_MIO10
G7
58
OTG_DATA1
G13
59
GND
-
60
GND
-
61
SD_CLK
E14
62
OTG_DATA2
B12
