ZYNQ FPGA Development Board AX7021 User Manual
l
Amazon Store: https://www.amazon.com/alinx
31 / 54
39
GND
-
40
GND
-
41
B33_L11_P
Y19
42
B13_L20_P
T4
43
B33_L11_N
AA19
44
B13_L20_N
U4
45
B33_L5_P
U20
46
B13_L3_P
W11
47
B33_L5_N
V20
48
B13_L3_N
W10
49
GND
-
50
GND
-
51
B33_L1_P
T21
52
B13_L10_P
Y11
53
B33_L1_N
U21
54
B13_L10_N
Y10
55
B13_L7_P
AA12
56
B13_L2_P
V8
57
B13_L7_N
AB12
58
B13_L2_N
W8
59
GND
-
60
GND
-
61
B13_L8_N
AB11
62
B13_L14_P
AA7
63
B13_L8_P
AA11
64
B13_L14_N
AA6
65
B13_L9_N
AB9
66
B13_L16_P
AB5
67
B13_L9_P
AB10
68
B13_L16_N
AB4
69
GND
-
70
GND
-
71
B13_L11_N
AA8
72
B13_L18_N
AA4
73
B13_L11_P
AA9
74
B13_L18_P
Y4
75
B13_L17_N
AB6
76
B13_L15_N
AB1
77
B13_L17_P
AB7
78
B13_L15_P
AB2
79
B13_L21_N
V4
80
B13_L21_P
V5
Table 2-14-2: Pin Assignment of CON2
CON3 Pin
Signal Name
ZYNQ Pin
CON3 Pin
Signal Name
ZYNQ Pin
1
B34_L2_P
J16
2
B34_L12_N
L19
3
B34_L2_N
J17
4
B34_L12_P
L18
5
B34_L11_P
K19
6
B34_L10_N
L22
7
B34_L11_N
K20
8
B34_L10_P
L21
9
GND
-
10
GND
-
11
B34_L7_P
J18
12
B34_L3_N
L16
13
B34_L7_N
K18
14
B34_L3_P
K16
