ARTIX-7 FPGA Development Board AX7035 User Manual
substantial research and development. In 2000, these companies
launched the SD Association (Secure Digital Association), which has
a strong lineup and attracted a large number of vendors. These
include IBM, Microsoft, Motorola, NEC, Samsung, and others.
Driven by these leading manufacturers, SD cards have become the
most widely used memory card in consumer digital devices.
The SD card is a very common storage device. The SD card
that we have extended supports SD and SPI modes. The SD card
used is a Micro SD card. The schematic diagram is shown in Figure
12-1.
Figure 12-1: SD Card Slot Schematic
Figure 12-2: SD Card Slot on the FPGA Board
