Electronic Door
Fittings of the PegaSys Series
Screwing on the interior fitting
With the
supplied screw set, loosely
screw on
the bottom part
s of the rose or plate.
With the mounting cyl
inder, align the door fi
tting.
The mounting cyl
inder has to move easily.
Now ti
ghten the screws.
Screw t
ight the set screw in the int
erior door
handle, make sure th
at it is flush.
Clamp on
rose or plate covering.
