Chapter 5
Programming Parameters
5–66
Testpoint Data #1
[Torq TP Sel 1]
Parameter Number 274
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
Testpoint Selection #2
[Torq TP Sel 2]
Parameter Number 275
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 0
Minimum Value 0
Maximum Value 100
Testpoint Data #2
[Torq TP Data 2]
Parameter Number 276
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
Testpoint Selection #3
[Torq TP Sel 3]
Parameter Number 277
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 0
Minimum Value 0
Maximum Value 100
Testpoint Data #3
[Torq TP Data 3]
Parameter Number 278
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
Testpoint Selection #4
[Torq TP Select 4]
Parameter Number 279
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 0
Minimum Value 0
Maximum Value 100
Testpoint Data #4
[Torq TP Data 4]
Parameter Number 280
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
This parameter contains the data selected
by Testpoint Selection #1 (param 273).
This parameter selects a torque block test
point. The value of that test point can be
read from Testpoint Data #2 (Parm 276).
This parameter contains the data selected
by Testpoint Selection #1 (param 275).
This parameter selects a torque block test
point. The value of that test point can be
read from Testpoint Data #3 (Parm 278).
This parameter contains the data selected
by Testpoint Selection #3 (param 277).
This parameter selects a torque block test
point. The value of that test point can be
read from Testpoint Data #4 (Parm 280).
This parameter contains the data selected
by Testpoint Selection #4 (param 279).
