Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–73
SCANport Start Mask
[Start Mask]
Parameter Number 332
Parameter Type Sink
Display Units Bits
Drive Units None
Factory Default 0111 1111
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter selects which SCANport
devices can issue a start command.
1 = Permit Control
0 = Deny Control
SCANport Jog Mask
[Jog Mask]
Parameter Number 333
Parameter Type Sink
Display Units Bits
Drive Units None
Factory Default 0111 1111
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter selects which SCANport
devices can issue a Jog command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
SCANport Clear Fault Mask
[Clear Fault Mask]
Parameter Number 335
Parameter Type Sink
Display Units Bits
Drive Units None
Factory Default 0111 1111
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter selects which SCANport
devices can issue a Clear Faults
command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
SCANport Reference Mask
[Reference Mask]
Parameter Number 334
Parameter Type Sink
Display Units Bits
Drive Units None
Factory Default 0111 1111
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter selects which SCANport
device can issue a reference command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
SCANport Direction Mask
[Direction Mask]
Parameter Number 331
Parameter Type Sink
Display Units Bits
Drive Units None
Factory Default 0111 1111
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter selects which SCANport
devices can issue a forward/reverse
command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
