Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–74
SCANport Reset Drive Mask
[Reset Drive Mask]
Parameter Number 336
Parameter Type Sink
Display Units Bits
Drive Units None
Factory Default 0111 1111
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter selects which SCANport
devices can issue a Reset Drive command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
SCANport Local Control Mask
[Local Mask]
Parameter Number 337
Parameter Type Sink
Display Units Bits
Drive Units None
Factory Default 0111 1111
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter selects which SCANport
devices can take local control.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
SCANport Stop Owner
[Stop Owner]
Parameter Number 340
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
devices are presently issuing a valid stop
command.
1 = Stop Input Present
0 = Stop Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
SCANport Direction Owner
[Direction Owner]
Parameter Number 341
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
device currently has exclusive control of
direction changes.
1 = Current Owner
0 = Non Owner
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
SCANport Start Owner
[Start Owner]
Parameter Number 342
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
devices are presently issuing a valid start
command.
1 – Start Input Present
0 – Start Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
