Chapter 5
Programming Parameters
5–75
SCANport Jog 1 Owner
[Jog 1 Owner]
Parameter Number 343
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
devices are presently issuing a valid jog 1
command.
1 = Jog 1 Input present
0 = Jog 1 Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
SCANport Reference Owner
[Reference Owner]
Parameter Number 345
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
device currently has exclusive control of
the reference changes.
1 = Current Owner
0 = Non Owner
SCANport Jog 2 Owner
[Jog 2 Owner]
Parameter Number 344
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
devices are presently issuing a valid jog 2
command.
1 = Jog 2 Input Present
0 = Jog 2 Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leavc Zero
SCANport Local Control Owner
[Local Owner]
Parameter Number 346
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
device currently has exclusive control of
the drive.
1 = Current Owner
0 = Non Owner
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
SCANport Flux Owner
[Flux Owner]
Parameter Number 347
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
devices are presently issuing a valid flux
command.
1 = Flux Input Present
0 = Flux Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
