Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–76
SCANport Ramp Owner
[Ramp Owner]
Parameter Number 349
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
devices are presently issuing a valid ramp
command.
1 = Ramp Input Present
0 = Ramp Input Not Present
SCANport Clear Fault Owner
[Clr Fault Owner]
Parameter Number 350
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
devices are presently issuing a valid Clear
Fault Command.
1 = Clear Fault Input Present
0 = Clear Fault Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
SCANport Process Trim Owner
[Trim Owner]
Parameter Number 348
Parameter Type Source
Display Units Bits
Drive Units None
Factory Default 0000 0000
Minimum Value 0000 0000
Maximum Value 0111 1111
Enums:
This parameter displays which SCANport
devices are currently issuing a valid
process trim command.
1 = Process Trim Input Present
0 = Process Trim Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
10 Volt In Filtr
[10 Volt In Filtr]
Parameter Number 352
Parameter Type
Display Units x.x r/s
Drive Units eng x 10 radian/sec.
Factory Default 0.0 r/s
Minimum Value 0.0 r/s
Maximum Value 200.0 r/s
This parameter establishes the breakpoint
radian frequency for the 10 Volt Input.
Pot In Filtr
[Pot In Filter]
Parameter Number 353
Parameter Type
Display Units x.x r/s
Drive Units eng. x 10 radian/sec
Factory Default 0.0 r/s
Minimum Value 0.0 r/s
Maximum Value 200.0 r/s
This parameter establishes the breakpoint
radian frequecy for the Pot Input.
mA In Filtr
[mA In Filter]
Parameter Number 354
Parameter Type
Display Units x.x r/s
Drive Units eng. x 10 radian/sec
Factory Default 0.0 r/s
Minimum Value 0.0 r/s
Maximum Value 200.0 r/s
This parameter establishes the breakpoint
for the mA Input.
