Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–77
10 Volt Input
[10 Volt Input]
Parameter Number 355
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
This parameter displays the converted
analog value of the +/– 10 volt input.
10 Volt Offset
[10 Volt Offset]
Parameter Number 356
Parameter Type Sink
Display Units +/– x.xx volt
Drive Units 205 = 1 volt
Factory Default +0.00 volt
Minimum Value –20.00 volt
Maximum Value +20.00 volt
This parameter determines the offset ap-
plied to the raw analog value of the +/– 10
volt input before the scale factor is applied.
This allows the user to shift the range of
the analog input.
10 Volt Scale
[10 Volt Scale]
Parameter Number 357
Parameter Type Sink
Display Units +/– x.xxx
Drive Units 2048 = 1
Factory Default +2.000
Minimum Value –16.000
Maximum Value +16.000
This parameter determines the scale factor
or gain for the +/– 10 volt input. The +/– 10
volt input is converted to +/– 2048 and
then the scale is applied which allows an
effective digital range of +/– 32767.
Pot Input
[Pot Input]
Parameter Number 358
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
This parameter displays the converted
analog value of the pot input.
Pot Offset
[Pot Offset]
Parameter Number 359
Parameter Type Sink
Display Units +/– x.xx volts
Drive Units 205 = 1 volt
Factory Default +0.000 volt
Minimum Value –20.000 volt
Maximum Value +20.000 volt
This parameter determines the offset
applied to the raw analog value of the pot
input before the scale factor is applied.
This allows the user to shift the range of
the of the analog input.
Pot Scale
[Pot Scale]
Parameter Number 360
Parameter Type Sink
Display Units +/– x.xxx
Drive Units 2048 = 1
Factory Default +1.000
Minimum Value –16.000
Maximum Value +16.000
This parameter determines the scale factor
or gain for the pot input. The pot input is
converted to a +/– 2048 and then the scale
is applied allowing an effective digital range
of +/– 32767
Milli Amp Input
[mA Input]
Parameter Number 361
Parameter Type Source
Display Units x
Drive Units None
Factory Default +0
Minimum Value 0
Maximum Value +32767
This parameter displays the converted
analog value of the milli amp input.
