Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–78
Milli Amp Input Offset
[mA Input Offset]
Parameter Number 362
Parameter Type Sink
Display Units + x.xxx mA
Drive Units 128 = 1mA
Factory Default +0.000 mA
Minimum Value –32.000 mA
Maximum Value +32.000 mA
This parameter determines the offset ap-
plied to the raw analog value of the milli
amp input before the scale factor is ap-
plied. This allows the user to shift the
range of the analog input.
Milli Amp Input Scale
[mA Input Scale]
Parameter Number 363
Parameter Type Sink
Display Units +/– x.xxx
Drive Units 2048 = 1
Factory Default +2.000
Minimum Value –16.000
Maximum Value +16.000
This parameter determines the scale factor
or gain for the milli amp input. The milli
amp input is converted to a +/– 2048 and
then the scale is applied which allows an
effective digital range of +/– 32767.
SCANport Analog1 Select
[SB Analog Sel]
Parameter Number 364
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 1
Minimum Value 1
Maximum Value 6
Enums:
This parameter selects which SCANport
analog device is used in parameter 365
‘SP Analog In’.
1 SCANport 1
2 SCANport 2
3 SCANport 3
4 SCANport 4
5 SCANport 5
6 SCANport 6
SCANport Analog1 In
[SB Analog1 In]
Parameter Number 365
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
This parameter displays the analog value
of the SCANport device selected in
parameter 364 ‘SP Analog Sel’.
SP Analog1 Scale
[SB Analog1 Scale]
Parameter Number 366
Parameter Type Sink
Display Units +/–x
Drive Units +/– 1, 1 = 32767
Factory Default 1 (32767)
Minimum Value –1 (–32767)
Maximum Value 1 (32767)
This parameter can be used to scale the
value in Parameter 365.
