Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–80
Analog Output 1 Scale
[An Out 1 Scale]
Parameter Number 372
Parameter Type Sink
Display Units +/– x.xxx
Drive Units 32767 = 1
Factory Default +0.500
Minimum Value –1.000
Maximum Value +1.000
This parameter determines the scale factor
or gain for Analog Output 1. A +/– 32767
digital value is converted by the scale fac-
tor which allows an effective digital range
of +/– 2048 which is then offset to provide
a +/– 10 volt range.
Analog Output 2
[Analog Out 2]
Parameter Number 373
Parameter Type Sink
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
This parameter converts a +/– 32767
digital value to a +/– 10 volt output.
Analog Output 2 Offset
[An Out 2 Offset]
Parameter Number 374
Parameter Type Sink
Display Units +/– x.xxx volt
Drive Units 205 = 1 volt
Factory Default +0.000
Minimum Value –20.000
Maximum Value +20.000
This parameter determines the offset ap-
plied to the raw analog output 2. The offset
is applied after the scale factor.
Analog Output 2 Scale
[An Out 2 Scale]
Parameter Number 375
Parameter Type Sink
Display Units +/– x.xxx
Drive Units 32767 = 1
Factory Default +0.500
Minimum Value –1.000
Maximum Value +1.000
This parameter determines the scale factor
or gain for Analog Output 2. A +/– 32767
digital value is converted by the scale fac-
tor which allows abn effective digital range
of +/– 2048 which is then offset to provide
a +/– 10 volt range.
Milli Amp Output
[mA Output]
Parameter Number 376
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 0
Minimum Value 0
Maximum Value +32767
This parameter converts a +/– 32767
digital value to a 4–20 mA output.
Milli Amp Output Offset
[mA Output Offset]
Parameter Number 377
Parameter Type Sink
Display Units +/– x.xxx mA
Drive Units 128 = 1mA
Factory Default 0.000 mA
Minimum Value –32.000 mA
Maximum Value +32.000 mA
This parameter determines the offset ap-
plied to the raw milli amp output. The off-
set is applied after the scale factor.
