Chapter 5
Programming Parameters
5–81
Milli Amp Output Scale
[mA Output Scale]
Parameter Number 378
Parameter Type Sink
Display Units +/– x.xxx
Drive Units 32767 = 1
Factory Default +0.500
Minimum Value –1.000
Maximum Value 1.000
This parameter determines the scale factor
or gain for milli amp output. A +/– 32767
digital value is converted by the scale fac-
tor which allows an effective digital range
of +/– 2048 which is then offset to provide
a +/– 20 mA range.
SCANport Analog Output
[SP Analog Out]
Parameter Number 379
Parameter Type Sink
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
This parameter displays the analog value
that is sent to all SCANports
Programmable Output Select
[Output Select]
Parameter Number 384
Parameter Type Sink,
Display Units x
Drive Units None
Factory Default 8
Minimum Value 0
Maximum Value 63
This parameter selects the function of
TB7–1 Output. The NOT column in the
following table indicates the value for the
inverse condition. For example: Entering
a value of 0 will result in a Run Ready
condition, while a value of 32
results in a NOT Run Ready condition.
NOT
EN
32 0 RUN READY
33 1 RUNNING
34 2 COMMAND DIRECTION
35 3 ROTATING DIRECTION
36 4 ACCELERATING
37 5 DECELERATING
38 6 WARNING
39 7 FAULTED
40 8 AT SET SPEED
41 9 LOCAL A
42 10 LOCAL B
43 11 LOCAL C
44 12 AT ZERO SPEED
45 13 REF A
46 14 REF B
47 15 REF C
NOT
EN
48 16 FLUX READY
49 17 FLUX UP
50 18 DIAGNOSTIC COMPLETED
51 19 DIAGNOSTIC ABORTED
52 20 BUS RIDETHRU
53 21 JOGGING
54 22 AUTOTUNE STAT A
55 23 AUTOTUNE STAT B
56 24 AT LIMIT
57 25 NOT USED
58 26 AT SETPOINT 1
59 27 AT SETPOINT 2
60 28 OVER SETPOINT 1
61 29 OVER SETPOINT 2
62 30 OVER SETPOINT 3
63 31 OVER SETPOINT 4
Set P66 to the type of Set Point desired,
Current or Speed.
Then set the appropriate parameter (P60 –
P65) to monitor your desired SetPoint.
To Next Page
