Allen-Bradley 1336 PLUS Troubleshoot Manual

5–10 Part Replacement Procedures
Publication 1336 IMPACT-6.2 – March 1998
!
ATTENTION: Wear a wrist-type grounding strap
when servicing 1336 IMPACT drives. Failure to
protect drive components against ESD may damage
drive components. Refer to Electrostatic Discharge
Precautions at the beginning of this chapter.
Important: Before you remove connections and wires from the
drive components, mark the connections and wires to
correspond with their component connections and
terminals to prevent incorrect wiring during assembly.
1. Remove power from the drive.
2. Check for zero volts at TB1 terminals +DC and –DC.
3. Check for absence of control voltage at:
• TB10
• TB11
• L Option Board (if used)
4. Remove the Snubber Board from the drive. Refer to
Chapter 3 – Disassembly and Access Procedures, Removing the
Snubber Board.
5. Unscrew the Thermistor from the heat sink.
Installation
Install the Thermistor in reverse order of removal.
Important: When fastening the Thermistor to the heat sink,
hand-tighten the Thermistor to avoid damaging the
porcelain Thermistor body.
!
ATTENTION: Replace all guards and insulators
before applying power to the drive. Failure to replace
guards may result in death or serious injury.
AB Spares

Allen-Bradley 1336 PLUS Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Frequency	0-400 Hz
Frequency	50/60 Hz
Dimensions	Varies by model
Weight	Varies by model
Enclosure	NEMA 1
Output Current	Varies by model
Power Rating	Varies by model
Communication	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Storage Temperature	-40 to 70°C (-40 to 158°F)
Humidity	5 to 95% non-condensing
Control Method	Sensorless Vector
