4–10 Component Test Procedures
Publication 1336 IMPACT-6.2 – March 1998
Bus Fuse F1 is located at the top of the heat sink.
Figure 4.4
Bus Fuse F1 Test
AB0331A
Bus Fuse
!
ATTENTION: Disconnect and lock out power from
the drive before disassembling the drive. Failure to
disconnect power may result in death or serious injury.
Verify bus voltage by measuring the voltage between
+DC and –DC on terminal block TB1. Do not attempt
to service the drive until the bus voltage has discharged
to zero volts.
Test 4 – Testing Bus
Fuse F1
