5–6 Part Replacement Procedures
Publication 1336 IMPACT-6.2 – March 1998
Installation
1. Place the bus bars through the center of the Ground Sense CT.
Refer to Figure 5.2.
2. Install the Ground Sense CT in reverse order of removal. Refer to
Table 3.A – Fastener Torque Specifications.
!
ATTENTION: Replace all guards and insulators
before applying power to the drive. Failure to replace
guards may result in death or serious injury.
