5–18 Part Replacement Procedures
Publication 1336 IMPACT-6.2 – March 1998
DC Bus Inductor L1
The DC Bus Inductor L1 is located on the lower left corner of the
drive, behind the Ground Sense CT.
Figure 5.8
DC Bus Inductor L1
Inductor bracket holes
align with studs on
Main Chassis
L3 wire to DC+
L1 wire to SCR1
Terminal C (–)
L4 wire to SCR1
Terminal A (+)
L2 wire to DC–
TB1 and Mounting
Plate
DC Bus
Inductor
AB0347A
