Allen-Bradley 1336 PLUS Troubleshoot Manual

1–14 Control Logic Wiring and Adapters
Publication 1336 IMPACT-6.2 – March 1998
All setup and operation information used by the drive is stored in a
system parameter table. Every parameter, including Setup and
Configuration parameters (Sources and Destinations), has an entry in
the parameter table. For example, parameter 29 is named the Speed
Ref 1 parameter and contains a number value representing the speed
reference. The speed reference can originate from an external control
device such as a potentiometer connected to the analog input of the
Main Control Board. Refer to the 1336 IMPACT User Manual,
Publication 1336 IMPACT-5.0.
AB Spares

Allen-Bradley 1336 PLUS Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Frequency	0-400 Hz
Frequency	50/60 Hz
Dimensions	Varies by model
Weight	Varies by model
Enclosure	NEMA 1
Output Current	Varies by model
Power Rating	Varies by model
Communication	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Storage Temperature	-40 to 70°C (-40 to 158°F)
Humidity	5 to 95% non-condensing
Control Method	Sensorless Vector
