Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 131
Measurement Definition Chapter 4
Table 25 - Primary Path Decimation Menu: SRD 22…36
Primary Path
Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX
SRD = 22 SRD = 24 SRD = 26 SRD = 28 SRD = 30 SRD = 32 SRD = 36
1 1873 1 1717 1 1585 1 1472 1 1374 1 1287 1 1144
2 312 2 286 2 264 2 245 2 229 2 215 2 191
3 208 3 191 3 176 3 163 3 153 3 143 3 127
4 156 4 143 4 132 4 123 4 114 4 107 4 95
5 125 5 114 7 75 6 82 6 76 5 86 5 76
8 78 7 82 10 53 9 54 8 57 8 54 7 54
11 57 10 57 14 38 13 38 12 38 11 39 11 35
16 39 15 38 - - - - - - - - - -
Table 26 - Alternate Path Decimation Menu: SRD 9…24
Alternate Path
Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX
SRD = 9 SRD = 12 SRD = 18 SRD = 20 SRD = 22 SRD = 24
1 4578 1 3434 1 2289 1 2060 1 1873 1 1717
2 1271 2 954 2 636 2 573 2 520 2 476
3 848 3 636 3 424 3 381 3 346 3 318
4 636 5 381 5 318 4 286 4 260 4 239
5 509 7 273 5 254 6 191 5 208 5 191
6 424 10 191 6 213 9 128 8 130 7 136
10 254 15 128 10 128 12 95 11 95 10 95
13196 2095 4398 1864 16 65 15 64
20128 3064 2064 3631 33 31 30 31
27 94 60 31 40 31 - - - - - -
4163-- -- -- ----
8031-- -- -- ----
Table 27 - Alternate Path Decimation Menu: SRD 26…36
Alternate Path
Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX
SRD = 26 SRD = 28 SRD = 30 SRD = 32 SRD = 36
1 1585 1 1472 1 1374 1 1287 1 1144
2 440 2 409 2 381 2 358 2 318
3 294 3 273 3 254 3 239 3 212
4 220 4 204 4 191 4 179 4 159
7 126 6 136 6 128 5 143 6 106
10 88 9 91 8 95 8 90 8 79
14 63 13 63 12 64 11 65 12 53
28 31 26 31 24 31 23 31 21 30
