130 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 4 Measurement Definition
16 858 9 763 10 458 11 312 12 229
18 768 10 687 12 381 15 229 18 153
20 687 11 624 15 305 22 156 24 114
22 624 15 528 20 229 30 114 36 76
26 528 15 458 30 153 46 75 49 56
30 458 18 381 40 114 61 56 73 38
36 381 22 312 61 75 91 38 - -
45 305 30 229 81 57 - - - -
61 225 45 153 121 38 - - - -
91 151 61 113 - - - - - -
122 113 92 75 - - - - - -
183 75 122 56 - - - - - -
243 57 182 38 - - - - - -
Table 24 - Primary Path Decimation Menu Selections: SRD 6…20
Primary Path
Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX
SRD = 6 SRD = 7 SRD = 9 SRD = 12 SRD = 18 SRD = 20
1 6867 1 5886 1 4578 1 3434 1 2289 1 2060
2 1144 2 981 2 763 2 572 2 381 2 343
3 763 3 654 3 509 3 381 3 254 3 229
4 572 4 490 4 381 5 229 4 191 4 172
5 458 5 392 5 305 7 163 5 153 6 114
6 381 6 327 6 254 10 114 6 127 9 76
7 327 8 245 10 153 15 76 10 76 12 57
10 229 13 151 13 117 20 57 13 59 18 38
15 153 17 115 20 76 30 38 20 38 - -
20 114 26 75 27 57 - - - - - -
30 76 35 56 41 37 - - - - - -
40 57 52 38 - - - - - - - -
61 38 - - - - - - - - - -
Table 23 - Primary Path Decimation Menu: SRD 1…5 (continued)
Primary Path
Dec FMAX Dec FMAX Dec FMAX Dec FMAX Dec FMAX
SRD = 1 SRD = 2 SRD = 3 SRD = 4 SRD=5
