Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 201
Configure Analog Outputs Chapter 6
Table 43 - Output Configuration Page Measurement Selection Options
Measurement Channel Type Measurement Type
Overall (0/1), Channel 0…3 Dynamic, gSE Any
Static Eccentricity
DC(V), Channel 0…3 Dynamic, gSE Any
Order magnitude (0…4), Channel
0…3
Dynamic Any
Order is Enabled
Order Phase (0…4), Channel 0…3 Dynamic Any
Order is Enabled
Order value is an integer (no fractions)
FFT Band (0…8), Channel 0…3 Dynamic, gSE Any
FFT Band is Enabled
Not 1X, Channel 0…3 Dynamic Any
Order 0 is Enabled
Order 0 value = 1.0
DC Channel 0…3 Static Any
SMAX magnitude, Channel Pair 0/1,
2/3
Dynamic X (shaft relative),
Y (shaft relative), Aeroderivative.
Shaft Relative (LP/HP filtered)
SMAX Phase, Channel Pair 0/1, 2/3
Shaft Absolute pk-pk, Channel Pair 0/
1, 2/3
Dynamic CH A =
Shaft Relative (LP/HP filtered)
CH B =
Std. case absolute vibration (AV to D)
or
Std. case absolute vibration (V to D)
Speed (0/1) If Speed input is Enabled Any
Factored Speed (0/1)
Speed maximum (0/1)
Speed Rate of Change (0/1)
Axial Differential Expansion, Channel
Pair 0/1, 2/3
Static CH A = Complementary Differential
Expansion A
CH B = Complementary Differential
Expansion B
Ramp Differential Expansion, Channel
Pair 0/1, 2/3
Static CH A = Ramp Differential Expansion A
CH B = Ramp Differential Expansion B
Rod Drop 0…3 Static Rod Drop
