202 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 6 Configure Analog Outputs
The Dynamix 1444 Series 1444-DYN04-01RA dynamic measurement
module can output analog representations of measured data in the 4…20 mA
format. The functionality is suitable for driving strip chart recorders, output to
analog meters, or to replace previous communication solutions that were
available in legacy systems. While 4…20 mA outputs are available, they are not
the preferred medium for data communication from the Dynamix system.
This page is presented only when an Analog Output Expansion Module
(1444-AOFX00-04RB) is present (See Expansion Device Definition Dialog
on page 94). When available, one per measurement module, this page is used to
configure the outputs.
