Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 271
Operate the Module Chapter 10
ProtectionLoopTimeWarning
Protection Loop Time Warning
DSP critical alarms loop cycle time >100 milliseconds. If set, module does not satisfy performance requirements of
API-670.
Tag is considered in MainModuleSummary fault if Compliance Mode set to API-670.
MainModuleSummary
Main Module Summary Fault
Summary fault bit for the main module. The status bit is set if any of the following status indicators are set:
Also see Summary Status Tags
on page 265.
Tag (continued) Description (if = 1)
DSP Dual Port Memory Fault Tag is hidden. Its state can be resolved from the DSP
status tag.
Non-recoverable Fault
+1.5V Power Supply OK Tag is hidden. Its state can be resolved from the DSP
status tag.
Power supply status tags are normally set
+1.6V Power Supply OK
DSP 3.3V Power Supply OK
5V Power Supply OK
25.5V Power Supply OK
+24V Power Supply OK
25.5 Power Supply OK
-24V Power Supply OK
AD Ch0&1 +6.5V Power Supply OK
AD Ch0&1 +5V Reference OK
AD Ch0&1 Monitored Power OK
AD Ch2&3 Monitored Power OK
DSP Memory Fault Tag is hidden. Its state can be resolved from the DSP
status tag.
DSPCRCError See Table 54 on page 269
.
DSPReset
CalFault
CalTimeout
MainRelayFault
ProtectionLoopTimeWarning
+5VA Power Supply Fault Tag is hidden. Its state can be resolved from the DSP
status tag.
+24V Power Supply Fault
-24V Power Supply Fault
