Allen-Bradley 1444-TSCX02-02RB User Manual

272 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 10 Operate the Module
ExpModuleSummary
Expansion Module Summary Fault
Summary fault for all connected expansion modules. The status bit is set if any of the following status indicators are
set:
Also see Summary Status Tags
on page 265.
Tag (continued) Description (if = 1)
Expansion Relay Modules
Relay Module Not Responding Tag is hidden. Its state can be resolved from the status
tag (ex. ExpRelay0Status) for each relay module.
Relay Module Configured
Relay Module CRC Error
Relay Module Link / Bus Fail
Relay Module RAM Fault
Relay Module RAM Access Error
ExpRelayNRelay0Fault (N=0,1,2) See Table 58 on page 274
.
ExpRelayNRelay1Fault
ExpRelayNRelay2Fault
ExpRelayNRelay3Fault
ExpRelayNFaultCode See Table 59 on page 276
.
Analog Output Module
Analog Output Module Not Responding Tag is hidden. Its state can be resolved from the status
tag, ExpAnalogStatus, described in Table 60 on
page 276.
Analog Output Module Configured
Analog Output Module CRC Error
Analog Output Module Link / Bus Fail
Analog Output Module RAM Fault
Analog Output Module RAM Access Error
ExpAnalogFaultCode See Table 59 on page 276
.
Tachometer Signal Conditioner Module
Tachometer Signal Conditioner Module Not Responding Tag is hidden. Its state can be resolved from the status
tag, ExpTachStatus, described in Table 61 on page 276
.
Tachometer Signal Conditioner Module Configured
Tachometer Signal Conditioner Module CRC Error
Tachometer Signal Conditioner Module Link / Bus Fail
Tachometer Signal Conditioner Module RAM Fault
Tachometer Signal Conditioner Module RAM Access Error
+25.5V Power Supply Fault
25.5V Power Supply Fault
ExpTachFaultCode See Table 59 on page 276
.
