Operate the Module Chapter 10
Table 55 - Transducer Status
Table 56 - Speed Status
Tag Description (if=1)
Ch0Enabled
Channel 0 Enabled
Channel is configured for dynamic or static measurements.
Ch1Enabled
Channel 1 Enabled
Channel is configured for dynamic or static measurements.
Ch2Enabled
Channel 2 Enabled
Channel is configured for dynamic or static measurements.
Ch3Enabled
Channel 3 Enabled
Channel is configured for dynamic or static measurements.
Transducer0Enabled
Transducer 0 Enabled
Set if Channel0Enabled is set, unless the sensor is self or externally powered, or is powered from
Channel 2 if a Dual Path personality is used.
Transducer1Enabled
Transducer 1 Enabled
Set if Channel1Enabled is set, unless the sensor is self or externally powered, or is powered from
Channel 3 if a Dual Path personality is used.
Transducer2Enabled
Transducer 2 Enabled
Set if Channel2Enabled is set, unless the sensor is self or externally powered, or is powered from
Channel 0 if a Dual Path personality is used.
Transducer3Enabled
Transducer 3 Enabled
Set if Channel3Enabled is set, unless the sensor is self or externally powered, or is powered from
Channel 1 if a Dual Path personality is used.
Transducer 0Fault
Transducer 0 Fault
Transducer 0 fault. Indicates bias out of range and/or detected wire off condition.
Transducer 1Fault
Transducer 1 Fault
Transducer 1 fault. Indicates bias out of range and/or detected wire off condition.
Transducer 2Fault
Transducer 2 Fault
Transducer 2 fault. Indicates bias out of range and/or detected wire off condition.
Transducer 3Fault
Transducer 3 Fault
Transducer 3 fault. Indicates bias out of range and/or detected wire off condition.
Transducer0WireOffDetected
Transducer 0 Wire Off Detected
Transducer 0 wire off condition detected.
Transducer1WireOffDetected
Transducer 1 Wire Off Detected
Transducer 1 wire off condition detected.
Transducer2WireOffDetected
Transducer 2 Wire Off Detected
Transducer 2 wire off condition detected.
Transducer3WireOffDetected
Transducer 3 Wire Off Detected
Transducer 3 wire off condition detected.
Tag Description (if=1)
Speed0Enabled
Speed 0 Enabled
Speed 0/1 is enabled. Since the AOP does not provide an "OFF" selection, these must always be set.
Speed1Enabled
Speed 1 Enabled
Tac h0Fault
Tach (Speed) 0 Fault
Speed 0/1 is in fault. Fault detection / indication depends on the speed Source selection.
The fault indication is associated with any type of speed input.
Tac h1Fault
Tach (Speed) 1 Fault
To Next Page
