298 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 10 Operate the Module
The results that are presented in Table 73 and Table 74 are based on a pure
sine-wave input signal. Actual measurements of complex signals vary.
Table 73 - Input: Sine-wave, 2 Vpp
Input: Sine-wave, 2 Vpp (-5 to -3V), ADC FMAX = 4578 Hz, No filtering
Measurements (volts RMS)
Values that are stated as "avg" are approximate as the measurement is varying by >10%
Frequency TC=0.5 (Default) TC=30 TC=60 Tracking Filter RPM
OAO OA1 OAO OA1 1xM 1xP
60 1.98 2.02 2.02 2.02 2.02 81 3600
50 1.98 2.02 2.02 2.03 2.02 81 3000
40 1.97 2.02 2.02 2.03 2.02 81 2400
30 1.94 2.02 2.02 2.03 2.02 80 1800
20 1.91 2.03 2.02 2.03 2.02 80 1200
15 1.87 2.02 2.02 2.03 2.02 80 900
10 1.83 2.02 2.02 2.05 2.02 80 600
9 1.81 avg 2.02 2.02 2.05 2.02 80 540
8 1.81 avg 2.02 2.02 2.06 2.02 80 480
7 1.75 avg 2.01 2.02 2.05 2.02 79 420
6 1.74 avg 2.02 2.01 2.02 2.02 79 360
5 1.68 avg 2.02 2.01 2.02 2.02 79 300
4 1.60 avg 2.03 2.01 2.08 2.02 78 240
3 1.52 avg 2.02 2.01 2.01 2.02 77 180
2 1.43 avg 1.98 2.00 2.10 2.00 75 120
1 0.85 avg 2.20 1.98 2.00 1.98 69 60
0.5 0.85 avg 1.75 avg 1.94 avg 1.99 avg 1.80 342 30
0.25 0.60 avg 1.70 avg 1.94 avg 1.99 avg 1.57 40 15
OA0 = Post Filter, OA1 = Mid-Filter
