Allen-Bradley 1444-TSCX02-02RB User Manual

Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 319
CIP Objects Appendix A
Time Slot Multiplier Page
Time Slot 0…3 TimeSlotMultiplier[0…3] Dynamix MUX Object Time Slot 0 DAQ Time Multiplier
HW Configuration Page
Xdcr Units Ch0…3Sensor.DCEngineeringUnits Dynamix Transducer Object Transducer DC Units
Xdcr Units Ch0…3Sensor.ACEngineeringUnits Dynamix Transducer Object Transducer AC Units
Xdcr Sensitivity Ch0…3Sensor.DCSensitivity Dynamix Transducer Object Transducer DC Sensitivity
Xdcr Sensitivity Ch0…3Sensor.ACSensitivity Dynamix Transducer Object Transducer AC Sensitivity
Xdcr Power Ch0…3Sensor.TranducerPower Dynamix Transducer Object TX Power Setup
Xdcr High Limit (V DC) Ch0…3Sensor.HLimit Dynamix Transducer Object Transducer OK High Threshold
Xdcr Low Limit (V DC) Ch0…3Sensor.LLimit Dynamix Transducer Object Transducer OK Low Threshold
Xdcr Location Ch0…3Description.Location Dynamix Transducer Object Transducer Location
Xdcr Orientation (deg) Ch0…3Description.0reintation Dynamix Transducer Object Transducer Orientation
Name Ch0…3Description.Name Dynamix Transducer Object Transducer Name
Measurement Type Module.Ch0…3AppTypeApplied Configuration Manager Object Channel Application Type
Pt0 (1) TripInhibitSource Dynamix Voted Alarm Object Trip Inhibit / Bypass source
AlarmResetSource Dynamix Voted Alarm Object Alarm Reset Source
VotedAlarm00…12.LogicInput Dynamix Voted Alarm Object Alarm Multiplier Control
VotedAlarm00…12.LogicGateSource Dynamix Voted Alarm Object Logic Gating Source
VotedAlarm00…12.LogicLogicSource Dynamix Voted Alarm Object Logic Control Source
Speed[0…1].TachFaultSource Dynamix Tacho and Speed
Measurement Object
Tacho OK Source
Pt0 (1) ModuleControl.Pt00…1OutputAssign Dynamix Module Control Object Opto Output 0…1 Allocation
Filters Page
FFT MAX (ADC) Ch0…3Filter.SampleRateDivisor Dynamix Channel Setup Object SRD
FFT MAX (Primary) Ch0…3Filter.FMAXDecimation Dynamix Channel Setup Object Decimation
Low Pass Filter (Primary) Frequency Ch0…3Filter.LowPassFreq Dynamix Channel Setup Object LP Filter -3 dB Point
High Pass Filter (Primary) Frequency Ch0…3Filter.HighPassFreq Dynamix Channel Setup Object HP Filter -3 dB Point
Alternate Processing Path Processing
Mode
Ch0…3Filter.AltPathMode Dynamix Channel Setup Object Alternate Path control
FFT FMAX (Alternate) Ch0…3Filter.AltPathFMAXDecimation Dynamix Channel Setup Object Decimation (attribute 23)
Alternate Path Tachometer Ch0…3Filter.SyncTachoSource Dynamix Channel Setup Object Synchronous Tacho Source
Alternate Path Synchronous Pulses Per
Revolution
Ch0…3Filter.SynchSamplesPerRevolution Dynamix Channel Setup Object Synchronous Samples Per Revolution
Overall Page
Overall (1) Signal Source Ch0…3Overall.SourceB Dynamix AC Measurement Object AC Overall Measurement Source
Overall (0) Signal Detection Ch
0…3Overall.SignalDetectionA Dynamix AC Measurement Object AC Overall magnitude - Detection
Method
Overall (1) Signal Detection Ch0…3Overall.SignalDetectionB Dynamix AC Measurement Object AC Overall magnitude - Detection
Method
Overall (0) Time Constant Ch0…3Overall.RMSTimeConstantA Dynamix AC Measurement Object AC Overall Measurement RMS TC
Ch0…3Overall.PkTimeConstantA Dynamix AC Measurement Object AC Overall Measurement Peak TC
Table 83 - Parameter – Tag – Object Attribute Cross-reference (continued)
Parameter Tag Member Object Attribute
